I will go so far as to say the new interface is less clear. I just had the experience of scanning the list trying to distinguish between icons in shades of grey to determine if a layer was on. The old checkbox was much easier to visually scan
@craftyjon That’s a little help, thanks. It does nothing for the grey on grey icons (I mean who thinks that’s an improvement over checkboxes) but the colour patches are reduced a little. They’re still way too large.
Quite frankly this whole toolbar change to the layers seems unnecessary and in the wrong direction.
Hmm, I have not had an issue in v7 pcb editor with the right-side appearance pane, but I have now opened the v7 footprint editor and the right pane is about three times wider than it was in v6. While the left pane can be dragged narrower, the right one cannot. Hardly any real-estate for editing a footprint anymore (or is there a setting I am missing?):
Thanks, Jon. Going to Start menu → KiCad 7.0 (the main application) → Context menu → Properties → Compatibility tab → Change high DPI settings → High DPI scaling override and choosing “System (Enhanced)” did the trick for me. Plain “System” made fonts blurry.
